New 2026 Ram 5500 Chassis Cab Tradesman Pickup Photo 1 of 1

New 2026 Ram5500 Chassis Cab Tradesman

    Exterior Color
    Bright White
    Interior Color
    Diesel Gray/Black
    Body/Seating
    Pickup/6 seats
    Transmission
    Automatic
    Drivetrain
    4x4
    Engine
    Cummins 6.7L I-6 diesel direct injection VVT intercooled turbo diesel engine with 360HP
    VIN
    3C7WRNFL5TG190976
    Ram 5500 Chassis Cab

    Highlighted Features

    • Emergency communication system
    • Wireless phone connectivity
    • Exterior parking camera rear
    • Perimeter/approach lights
    • Remote keyless entry
    • Fully automatic headlights
    • Dual rear wheels
    • Heated door mirrors
    • Trailer sway control

    Included Packages & Accessories

    • Quick Order Package 25A Tradesman
    • ParkView Rear Back-Up Camera
    • 50 State Emissions
    • Tradesman Level 1 Equipment Group
    • Black Exterior Mirrors
    • Power-Adjustable Convex Aux Mirrors
    • Exterior Mirrors with Supplemental Signals
    • Exterior Mirrors Courtesy Lamps
    • Exterior Mirrors with Heating Element
    • Manual Folding Exterior Mirrors
    • Manuarl Telescoping Mirrors
    • Black Power Heated Fold Telescope Mirrors
    • Mirror Running Lights
    • Power Adjust Mirrors
    • Rear Window Defroster
    • Trailer Brake Control
    • Trailer Light Check
    • Dual 730 Amp Maintenance Free Batteries
    • Supplemental Heater
    • Cummins Turbo Diesel Badge
    • Smart Diesel Exhaust Brake
    • Current Generation Engine Controller
    • Selective Catalytic Reduction
    • Transfer Case Skid Plate Shield
    • Power Take-Off Right/Left
    • Clean Idle Emissions Label
    • B-20 Bio Diesel Capability
    • 6.7L I6 Cummins Turbo Diesel Engine
    • 19,500 lbs GVWR
    • 8-Speed TorqueFlite HD Automatic Transmission

    Included Packages & Options

    • 6.7L I6 Cummins Turbo Diesel Engine$9,995
      • B-20 Bio Diesel Capability
      • Clean Idle Emissions Label
      • Cummins Turbo Diesel Badge
      • Current Generation Engine Controller
      • Dual 730 Amp Maintenance Free Batteries
      • 19,500 lbs GVWR
      • Selective Catalytic Reduction
      • Smart Diesel Exhaust Brake
      • Supplemental Heater
    • 8-Speed TorqueFlite HD Automatic Transmission$1,000
      • Power Take-Off Right/Left
      • Transfer Case Skid Plate Shield
    • Tradesman Level 1 Equipment Group$895
      • Black Exterior Mirrors
      • Power-Adjustable Convex Aux Mirrors
      • Exterior Mirrors with Supplemental Signals
      • Exterior Mirrors Courtesy Lamps
      • Exterior Mirrors with Heating Element
      • Manual Folding Exterior Mirrors
      • Manuarl Telescoping Mirrors
      • Black Power Heated Fold Telescope Mirrors
      • Mirror Running Lights
      • Power Adjust Mirrors
      • Rear Window Defroster
      • Trailer Brake Control
    • Trailer Brake Control$465
      • Trailer Light Check
    Included Options
    • ParkView Rear Back-Up Camera$495

    Detailed Specifications

    • 1-touch down
    • 1-touch up
    • Adaptive Cruise Control
    • Air conditioning
    • Driver door bin
    • Emergency communication system: RAM Connect
    • Front beverage holders
    • Overhead console
    • Passenger door bin
    • Passenger vanity mirror
    • Power windows
    • Proximity key: push button start only
    • Rear beverage holders
    • Rear door bins
    • Remote keyless entry
    • Speed control
    • Tilt steering wheel
    • Voice recorder
    • Dual rear wheels
    • Front anti-roll bar
    • Front tires: 225/70R19.5G
    • Power steering
    • Rear anti-roll bar
    • Rear tires: 225/70R19.5G
    • Wheel size: 19.5"
    • 1st row LCD monitors: 2
    • AM/FM radio: SiriusXM
    • Primary LCD size: 8.4"
    • Radio data system
    • Satellite radio trial duration with new vehicle purchase (months): 6
    • Smart device integration: Apple CarPlay/Android Auto
    • Speakers: 6
    • Wireless phone connectivity: Uconnect w/Bluetooth
    • Basic warranty: 36 months/36,000miles
    • Corrosion perforation warranty: 60 months/100,000miles
    • Diesel engine warranty: 60 months/100,000miles
    • Powertrain warranty: 120 months/100,000miles
    • Roadside assistance coverage: 60 months/100,000miles
    • Front center armrest: w/storage
    • Front seats: bench
    • Max seating capacity: 6
    • Rear seats: bench
    • Rear seats Folding position: fold-up cushion
    • Seat Upholstery: vinyl
    • Compressor: intercooled turbo
    • Cylinder configuration: I-6
    • Cylinder deactivation
    • Drive type: four-wheel
    • Engine liters: 6.7L
    • Engine location: front
    • Fuel tank capacity: 52.0gal.
    • Horsepower: 360hp @ 2,800RPM
    • Hybrid traction battery type: none
    • Limited slip differential: mechanical
    • Mode select transmission
    • Number of valves: 24
    • Recommended fuel: Diesel
    • Sequential multi-point fuel injection
    • Standard fuel economy fuel type: diesel
    • Torque: 800 lb.-ft. @ 1,800RPM
    • Transmission: 8 speed automatic
    • Variable intake manifold
    • Variable valve control
    • Approach angle: 26 deg
    • Departure angle: 28 deg
    • Ground clearance (max): 218mm (8.6")
    • Ground clearance (min): 206mm (8.1")
    • Ramp breakover angle: 20 deg
    • Heated door mirrors
    • Left rear passenger door: conventional
    • Power door mirrors
    • Right rear passenger: conventional
    • Skid plates
    • Trailer sway control
    • Turn signal indicator mirrors
    • Compression ratio: 16.20 to 1
    • Curb weight: 4,076kg (8,987lbs)
    • Engine bore x stroke: 107.0mm x 124.0mm (4.21" x 4.88")
    • Engine displacement: 6.7 L
    • Engine torque: 800 lb.-ft. @ 1,800RPM
    • Exterior body width: 2,207mm (86.9")
    • Exterior height: 2,068mm (81.4")
    • Exterior length: 7,346mm (289.2")
    • Front headroom: 1,039mm (40.9")
    • Front hiproom: 1,598mm (62.9")
    • Front legroom: 1,039mm (40.9")
    • Front shoulder room: 1,674mm (65.9")
    • GVWR: 8,845kg (19,500lbs)
    • Passenger volume: 3,528L (124.6 cu.ft.)
    • Payload: 4,767kg (10,510lbs)
    • Rear headroom: 1,011mm (39.8")
    • Rear hiproom: 1,593mm (62.7")
    • Rear legroom: 1,021mm (40.2")
    • Rear shoulder room: 1,666mm (65.6")
    • Towing capacity: 12,864kg (28,360lbs)
    • Turning radius: 9.1m (29.8'')
    • Wheelbase: 5,014mm (197.4")
    • Appearance: analog
    • Compass
    • Delay-off headlights
    • Exterior parking camera rear: ParkView yes
    • Front fog lights
    • Front reading lights
    • Fully automatic headlights
    • Outside temperature display
    • Rear reading lights
    • Rear window defroster
    • Tachometer
    • Variably intermittent wipers
    • Voltmeter
    • 4 wheel disc brakes
    • ABS brakes
    • Dual front impact airbags
    • Electronic stability
    • Forward collision: Forward Collision Warning-Plus mitigation
    • Front pedestrian detection: prevention
    • Ignition disable
    • Occupant sensing airbag
    • Panic alarm
    • Perimeter/approach lights
    • Tracker system: RAM Connect
    • Traction control

    Standard Features

    • B-20 Bio Diesel Capability
    • Clean Idle Emissions Label
    • Cummins Turbo Diesel Badge
    • Current Generation Engine Controller
    • Dual 730 Amp Maintenance Free Batteries
    • 19,500 lbs GVWR
    • Selective Catalytic Reduction
    • Smart Diesel Exhaust Brake
    • Supplemental Heater
    • Power Take-Off Right/Left
    • Transfer Case Skid Plate Shield
    • Black Exterior Mirrors
    • Power-Adjustable Convex Aux Mirrors
    • Exterior Mirrors with Supplemental Signals
    • Exterior Mirrors Courtesy Lamps
    • Exterior Mirrors with Heating Element
    • Manual Folding Exterior Mirrors
    • Manuarl Telescoping Mirrors
    • Black Power Heated Fold Telescope Mirrors
    • Mirror Running Lights
    • Power Adjust Mirrors
    • Rear Window Defroster
    • Trailer Brake Control
    • Trailer Light Check

    Dealer Notes

    You won't want to miss this excellent value!

    It offers the latest in technological innovation and style. Turbocharger technology provides forced air induction, enhancing performance while preserving fuel economy. All of the following features are included: 1-touch window functionality, tilt steering wheel, and power windows. It features four-wheel drive capabilities, a durable automatic transmission, and a refined 6 cylinder engine.

    Our team is professional, and we offer a no-pressure environment. We'd be happy to answer any questions that you may have. We are here to help you.

    MSRP
    $77,545
    Advertised Price
    Please Call
